Quanta Q Plus C Evo Series

Q – Switched Nd Yag 1064nm, 532nm & Ruby 694nm

SPECIFICATIONS

Laser: Q-Switched Nd Yag and Q-Switched Ruby

Wavelength: 1064nm, 532nm, and 694nm

Pulse Width: 1064nm = 6ns, 532nm = 6ns, 694nm = 30ns

Repetition Rate: 1064nm = up to 10 Hz, 532nm = up to 10 Hz, 694nm = up to 3 Hz

Spot Size: 1064nm = up to 5x5mm, 532nm = up to 5x5mm, 694nm = up to 5x5mm

Max Fluence: 1064nm = up to 22 J/cm2, 532nm = up to 11 J/cm2, 694nm = up to 25 J/cm2

Electrical Requirements: 230 VAC; 16 A; 50/60 Hz

Dimensions: 400 (W) x 900 (D) x 930 (H) mm3

Weight: 90 Kg
